Investment Casting Partners
Our investment casting partners and affiliates have a proven track record of producing precision investment casting parts from a variety of metals in varying shapes & sizes.
The world class metal casting companies in India has operational capacity of over 500,000 lbs a month. The facilities are ISO 9001, ISO 14001, ISO 45001, PED/W0, NORSOK M-650 and Lloyd’s Register certified, in addition to several other accreditations and approvals from large end-customers.
Investment Casting Snapshot
500K LBS
Production Capacity per month
3+
Decade of Experience
100%
Powered by renewable energy
Metals Handled
Our Partners & Affiliates manufacture precision investment castings in various ferrous and non-ferrous metal chemistries including:
Stainless Steel
CF8M, CF3M, CA—40, CK3MtCu , CN7M, 1.4308, 1.4408, 1.4581
Carbon & Low Alloy Steel
WCB, WCC, LCB, LCC, 1.0619
Duplex Stainless Steel
CD4MCuN, GR-4A, GR-5A, GR-6A
Nickel Alloy
CW12MW, CZ-100, M35-1, CW6MC, CU5JCuC, N12MV
Cobalt Alloys
Stellite—6, Stellite—12
Aluminum Alloys
LM-25, LM-6, LM-9
Copper Alloys
HTB-1,Gunmetal(85-5-5-5),TinBronze,PhosphorusBronze
Austenitic Ductile Iron
D2 (Ni-Resist)
Precipitation Hardening Stainless Steel
CB7Cu-1, CB7Cu-2
Value Added Services
- Machining
- Powder coating
- Zinc & Nickel Plating
- Manganese Phosphating
- Anodizing for Aluminum Components
Manufacturing Capabilities
SINGLE PIECE SIZE
350 x 350 x 200 mm (Max.)
25 x 10 x 5 mm (Min.)
SINGLE PIECE WEIGHT
0.05 to 80 Kg.
Product Category
- Automotive Sector
- General Engineering
- General Engineering
- Oil & Gas industry
- Pumps
- Valves
Machining Shop Capabilities
- CNC Vertical Milling Centers
- CNC Turning Centers
- Horizontal Machining Center
- Turning & Milling Center
- Machining Jig & FixtureDesign
Testing Capabilities
- 2-D Height Gauge
- Chemical Analysis (Spectro Analysis)
- Coordinate Measuring Machine
- Hardness Testing
- Hydro Testing up to 20,000 psi
- Impact Testing
- Intergranular Corrosion Testing
- Mechanical Testing
- Metallurgical Microscope
- Radiation Measurement
- Roughness Testing
